RKS.161.14.1094 Slewing Bearings

The RKS.161.14.1094 is a external-tooth four-point contact ball slewing bearing, belonging to the RKS series of lightweight and precision slewing bearings. It is a universal heavy-duty rotary component that integrates compact structure, high load-bearing capacity and stable rotational accuracy. Specially designed for industrial equipment requiring medium and light load, continuous rotation and high-precision operation, this model has become a core load-bearing and transmission part for small and medium-sized rotary equipment, thanks to its balanced mechanical performance, ultra-compact cross-section and convenient installation structure. It is widely compatible with construction machinery, automated equipment and special operation facilities.

1. Core Specification Parameters

This product features standardized parameters and precise dimensional tolerance, fully complying with mainstream industrial installation standards. Its core dimensions and basic specifications are as follows:

• Model Number: RKS.161.14.1094
• Gear Structure: External gear drive, compatible with external driving mechanisms, featuring high transmission efficiency and easy disassembly & assembly
• Nominal Raceway Diameter (dm): 1094mm
• Outer Diameter (D): 1198.4mm
• Outer Ring Mounting Diameter (D1): 1096mm
• Inner Diameter (d): 1024mm
• Product Weight: 91kg
• Structure Type:Single-row four-point contact ball rotary structure
• Accuracy Grade: Customizable P4/P5/P6 precision grades; standard factory accuracy meets general industrial working conditions

2. Structure, Material & Processing Technology

The RKS.161.14.1094 adopts the classic fixed thin-section lightweight structure of the RKS series. Its cross-section size remains stable regardless of inner and outer diameter changes, featuring an extremely compact overall structure that occupies minimal equipment space and effectively reduces the overall weight and volume of complete machines.

The main body is forged from 42CrMo high-strength bearing steel. The raceways are processed by high-frequency quenching and precision grinding, reaching a hardness of 55-62HRC. It delivers excellent wear resistance, fatigue resistance and impact resistance, supporting long-term operation under alternating loads. The gear parts are machined in strict accordance with DIN 3967 industrial gear standards with precise tooth profiles and stable meshing, greatly reducing transmission noise and mechanical wear.

Equipped with a double-sided contact sealing system and high-quality aging-resistant sealing strips, the bearing effectively blocks dust, sediment, rainwater and other contaminants from entering the interior and prevents grease leakage, adapting to harsh working environments with dust, humidity and open-air exposure. Reserved radial grease nipples support regular manual lubrication and automatic lubrication system matching, realizing low-maintenance operation.

3. Core Performance Advantages

• Multi-directional Composite Load Capacity: The four-point contact ball structure can bear radial load, axial load and overturning moment simultaneously, with balanced force bearing and excellent mechanical stability, suitable for rotary operation scenarios with complex stress conditions.
• High Rotational Accuracy & Low Running Resistance: Precision ground raceways and standard tooth profiles ensure smooth rotation and stable start-stop performance, no stalling at low speed and no jitter at high speed, fully meeting high-precision operation requirements of automated equipment.
• Strong Installation Compatibility: Standard prefabricated mounting bolt holes on both inner and outer rings require no complex modification. It is compatible with various standard mounting bases with simple installation, disassembly and replacement processes, greatly reducing equipment operation and maintenance costs.
• Excellent Weather Resistance: Stable operation in a wide temperature range of -30℃ to +120℃, with outstanding cold resistance, heat resistance and corrosion resistance, adapting to open-air, low-temperature and other harsh working conditions.
• High Cost Performance: The lightweight structure balances high strength and low self-weight. Compared with heavy-duty cross roller bearings, it has lower cost and energy consumption, perfectly matching long-term continuous operation under medium and light load conditions.

4. Main Application Scenarios

With its compact structure, stable performance and strong compatibility, the RKS.161.14.1094 slewing bearing is widely used in various medium and light-load rotary equipment, covering the core fields below:

• Medium and Small Construction Machinery: Rotary mechanisms of truck-mounted cranes, mini cranes, aerial work platforms, rotary ladders and other equipment;
• Automated Intelligent Equipment: Large rotary worktables, automatic sorting turntables, rotary mechanisms of intelligent warehousing systems;
• Environmental Protection & Special Equipment: Rotary dust removal equipment, landscape rotary facilities, auxiliary rotary devices of small wind power equipment;
• Precision Industrial Equipment: Rotary bases of testing equipment, light-duty CNC rotary worktables and other precision transmission scenarios.

5. Operation Maintenance & Customization Service

This slewing bearing supports standardized batch supply and personalized customization of precision grades, sealing forms and gear parameters to meet the transformation needs of non-standard equipment. All products undergo strict load testing, precision inspection and tightness testing before delivery, complying with ISO industrial bearing standards, with long service life and low failure rate. Daily maintenance only includes regular grease refilling and sealing condition inspection, ensuring long-term stable operation and extremely low comprehensive maintenance cost.
